A true classic for the modern age, Rain Dial Series controller have been relied upon for generations to perform day-after-day, season-after-season.
Available in 6, 9 or 12 station models in an Outdoor cabinet.
Highlights
- 6, 9 and 12-station models
- 3 independent programs
- 3 water day choices
-
- Any day of the week
- Skip Days
- Odd or Even Days
-
- Permanent memory during power outage
- Water budgeting
- Snap-out face panels
- 9 and 12-Station models have 12-station terminal boards allowing interchange front panels to change station number
- Self-diagnostic Circuit Breaker
Features
6, 9 and 12-Station Models
Provides irrigation control for most sizes of residential landscapes
Non-volatile memory
Retains user’s program during power outages
Water budgeting per program
For quick changes to the watering durations of all stations on a program at one time. Changes, in 10% increments, reduce the need to readjust individual station running times for an entire program, 0-200%
365 calendar for odd/even date watering
Meets the Odd/Even date watering mandates often used for landscape water reductions
Master valve/pump start circuit assignable per station
Stations requiring a booster pump can be supplied while other stations can run on street water pressure
Bore level recovery (delay between stations
0-59 secs, 1-59 mins, 1-2 hrs (Option of pump circuit ON or OFF during delay) Bores that need recovery time from ground water between stations would not need the pump circuit on between stations
Rain delay up to 9 days
Saves water by allowing a manual setting of days of delay before automatically resuming the watering schedule.
Test all stations program
Allows a quick test of all stations from lowest to highest zone number
Manual station advance
During automatic, semi- automatic, and station test cycles, allows advancement of operation up through the stations
Clear/erase memory by program
Saves time by quickly erasing the program desired while leaving the others intact
Program stack or overlap option
Allows three programs/stations on at once or restricts operation to no overlapping station runs (to prevent too many valves on at one time)
Specifications
- Operating Specifications:
- Station Run Times: 1-59 minutes in 1 minute increments or 1-5.9 hours in 0.1 hour increments
- Start Times: 3 per program per day for 9 starts total
- Watering schedules per program:
- Any day of the week
- Skip days from 1 to 31 days between irrigations days
- Odd or even date watering
- Electrical Specifications:
- Transformer input: 240 VAC, 50 Hz
- Transformer output: 24 VAC, 1.25 amps
- Maximum output per station: 24 VAC, 0.5 amps
- Maximum output to valves: 24 VAC, 1.0 amps (including master valve/ pump start circuit)
- Program memory: non-volatile
